供應博士力矩電機應用0821200009

 a mounting flange, and an electrical connection through a junction box or connector.

The back of the cooling housing is open and the rotor is connected to the shaft and the bearing on the machine side.

It is characterized by the best way to combine standard solutions with free design integrated direct drive technology.

Reduced design effort and ease of maintenance have resulted in significant cost advantages.

IndraDyn T 系列力矩電機是采用液體冷卻的內裝電機，其經過優化，

較大力矩可達 13,800 Nm。由一個帶三相交流線圈的定子和一個永磁鐵轉子組成。

 此類電機的典型應用領域主要包括回轉工作臺中的直接驅動或加工中心或印刷單元的旋轉軸。

但是，在機器人應用，塑料機、木加工機、車床和特殊機械上，

該電機系統也可以提供創新的機械制造解決方案。

IndraDyn T series torque motor is a liquid-cooled built-in motor, which is optimized,

Maximum torque up to 13,800 Nm. Consists of a stator with a three-phase AC coil and a permanent magnet rotor.

  Typical applications for this type of motor include

the direct drive in the rotary table or the rotary axis of the machining center or printing unit.

MST 定子上的“冷卻罩”選項由閉路式冷卻罩、安裝法蘭和通過接線盒或接頭的電氣連接組成。

冷卻外殼的背面敞開，轉子與機器一側的軸和軸承相連。

其特點是以較佳方式將標準解決方案和自由設計集成直接驅動技術結合在一起。

減少設計工作量和便于維修的安裝方式帶來了巨大的額外成本YS。

However, in the robot applications, plastic machines, wood processing machines, lathes and special machinery,

The motor system can also provide innovative mechanical manufacturing solutions.

The "cooling hood" option on the MST stator consists of a closed cooling hood,
